Technical Features
| TS400PN | TS750PN | |
| ATEX zone | 22 | 22 |
| Marking | Ex II 3D Ex tc IIIB T135°C X Dc | Ex II 3D Ex tc IIIB T135°C X Dc |
| Voltage (V-Hz) | 400-50 3~ | 400-50 3~ |
| Power (kW) | 4 | 5,5 |
| Max waterlift (mmH₂O) | 3200/2600 | 3600/3000 |
| Airflow (mᶟ/h) | 420 | 530 |
| Capacity (l) | 100 | 100 |
| ø Suction inlet (mm) | 80 | 80 |
| Noise level dB(A) (EN ISO 3744) | 70 | 70 |
| Dry primary filter | Cartridge | Cartridge |
| Dry Media, class | Polyester ANT M | Polyester ANT M |
| Dry surface, diameter (cm²-mm) | 57.000 | 80.000 |
| Load on filter (m³/m²/h) | 74 | 66 |
| Filter cleaning system | Pneumatic, reverse air pulse | Pneumatic, reverse air pulse |
| Dimensions (cm) | 66x118x187h | 66x118x187h |
| Weight (kg) | 145 | 180 |
Download Brochures
Any questions? Please get in touch.
ABSOLUTE FILTER
STAINLESS STEEL FILTER CHAMBER AND CONTAINER
ADDITIONAL SILENCER
LIFTING EYEBOLTS/ AVAILABLE WITH FORK LIFT INTAKES
