Technical Features
| 220BL | 220BLLP | |
| ATEX zone | 22 | 22 |
| Marking | Ex II 3D Ex tc IIIB T135°C X Dc | Ex II 3D Ex tc IIIB T135°C X Dc |
| Voltage (v - Hz) | 230-50 1~ | 230-50 1~ |
| Power (kW) | 1,1 | 1,1 |
| Max waterlift (mmH₂O) | 2250 | 2250 |
| Max airflow (m³/h) | 215 | 215 |
| Ø Suction inlet (mm) | 50 | 50 |
| Container | AISI304 | - |
| Capacity (l) | 20 | Endless Bag |
| Filter cleaning system | Dustop | Dustop |
| DRY primary filter | Cartridge | Cartridge |
| Filtering media, grade DRY | Polyester ANT M | Polyester ANT M |
| Surface, diameter DRY (cm²-mm) | 30.000-360 | 30.000-360 |
| Load on filter (m³/m²/h) | 72 | 72 |
| Noise level dB(A) (EN ISO 3744) | 74 | 74 |
| Dimensions (cm) | 50x48x125h | 50x48x125h |
| Weight (kg) | 35 | 55 |
